A Phillips recess, shown cut into a plain cylinder. The module behind it is a cutting tool: it takes a shape and removes the cross from it.
The image shows the solid OpenSCAD renders at width 7 · thickness 0 · blank 12.
Phillips driver tip
remixcad/phillips-tip@1.0.0
Report
For a legal or policy problem: a license violation, personal data, somebody else’s work republished as their own. A model that prints badly is a comment, not a report.
Parameters
from sourceDescription
What is this
A Phillips recess, shown cut into a plain cylinder. The module behind it is a cutting tool: it takes a shape and removes the cross from it.
What you use it for
Subtract it from a bolt head, a knob or a thumbscrew of your own and a real driver will fit. The cylinder here is just something to cut into, so you can see the shape and check the size.
Design notes
This is the same recess the countersunk bolt in this collection uses, so anything cut with it takes the same driver as that bolt.
Because the module removes rather than adds, calling it with nothing to cut gives you nothing at all. That is worth knowing before you import it.
Parameters
width is measured across the tip and decides which driver fits. blank only sets the test cylinder. Leave thickness at zero unless the recess has to be looser than standard.
Use with your agent
{
"mcpServers": {
"remixcad": {
"type": "http",
"url": "https://remix-cad.vercel.app/api/mcp"
}
}
}get_model("remixcad/phillips-tip@1.0.0")Returns the manifest, the source, the import closure and the license obligations. Full MCP setup.
Parameter table
Parsed from the Customizer annotations in main.scad| Name | Default | Range | Unit | Description |
|---|---|---|---|---|
| width | 7 | 3 to 16 step 1 | mm | Across the tip, which sets the driver size. |
| thickness | 0 | 0 to 6 step 0.5 | mm | Thickness of the blades. Zero takes the default for the width. |
| blank | 12 | 6 to 30 step 1 | mm | Diameter of the cylinder the recess is cut into. |
Lineage
0 models depend on this oneOnly what this model came from and what came from it.
License
Whoever downloads this takes these obligations along- remixcad/phillips-tip@1.0.0 is CC0
- remixcad/threads@1.0.0 is CC0
Source
main.scad is the entrypointmain.scad
// Uses threads.scad by Ryan A. Colyer, released with CC0 into the public domain. Published on RemixCAD as remixcad/threads.
use <remixcad/threads/threads.scad>
width = 7; // [3:1:16]
thickness = 0; // [0:0.5:6]
blank = 12; // [6:1:30]
// PhillipsTip cuts its shape out of whatever it is given, so this hands it a plain
// cylinder. Do the same in your own model to get the recess in a head of your own.
PhillipsTip(width, thickness) cylinder(d = blank, h = width, $fn = 48);
